Gate Valve / Globe Valve / Check Valve

Home  Products  Gate Valve / Globe Valve / Check Valve

Cast Steel Gate Valve

The Mecco cast steel gate valves are available in two main types: wedge gate valves and slab gate valves.Wedge gate valves are designed and manufactured according to API 600 and GB/T 12234 standards, with pressure ratings of CL150, CL300, CL600, CL900, CL1500, and CL2500 (or PN16–PN420). If other pressure ratings are required, ASME B16.34 or GB/T 12224 can be followed. Operating temperature is -29°C to 538°C.Slab gate valves are designed and manufactured according to API 6D and GB/T 19672 standards, with the same pressure ratings and temperature range as the wedge gate valves.
Product Details
Cast Steel Globe Valve

The Mecco cast steel globe valves are designed and manufactured in compliance with API 623, BS 1873, and GB/T 12235 standards. They are available in pressure ratings of CL150, CL300, CL600, CL900, CL1500, and CL2500 (or PN16–PN420). If other ratings are needed, ASME B16.34 or GB/T 12224 can be applied. The operating temperature range is -29°C to 538°C.
Product Details
Cast Steel Check Valve

The Mecco cast steel check valves are designed and manufactured according to API 6D, API 594, BS 1868, GB/T 12235, and GB/T 12236 standards. Pressure ratings include CL150, CL300, CL600, CL900, CL1500, and CL2500 (or PN16–PN420). If additional pressure levels are required, the design can be based on ASME B16.34 or GB/T 12224. The temperature range is -29°C to 538°C.
Product Details
Forged Steel Gate Valve

MECCO Compact Forged Steel Check Valves are designed and manufactured in accordance with API 602, ISO 15761, JB/T 7746, and other relevant standards. Pressure ratings include CL150, CL300, CL600, CL800, and CL1500 (or PN16 to PN250). If the customer requires CL2500 or other pressure classes, the valves can be designed in accordance with ASME B16.34 or GB/T 12224. Operating temperature range: -29℃ to 538℃. The standard configuration is reduced bore; full bore can be provided upon request as specified in the contract.
Product Details
Forged Steel Globe Valve

The Mecco compact forged steel globe valve is designed and manufactured in accordance with API 602, ISO 15761, and JB/T 7746 standards. It is available in pressure ratings of CL150, CL300, CL600, CL800, and CL1500 (or PN16–PN250). If CL2500 or other pressure ratings are required, the design can follow ASME B16.34 or GB/T 12224. The operating temperature range is -29°C to 538°C. The standard configuration is reduced bore; full bore can be provided upon contractual agreement.
Product Details
Forged Steel Check Valve

The Mecco compact forged steel check valve is also designed and manufactured according to API 602, ISO 15761, and JB/T 7746 standards, with pressure ratings of CL150, CL300, CL600, CL800, and CL1500 (or PN16–PN250). For CL2500 or other pressure requirements, the valve can be designed per ASME B16.34 or GB/T 12224. Operating temperature is -29°C to 538°C. The standard design is reduced bore; full bore is available by contract specification.
Product Details
Forged Large-Diameter GGC Valves

In some special service conditions where high quality is essential and customers cannot accept the potential risks associated with casting—such as in high-pressure hydrogenation, oxygen service, or toxic media—customers may choose forged materials even for large-diameter, moderate-pressure applications where casting is typically used. These products follow the same applicable standards and scope as the cast gate valves, globe valves, and check valves mentioned previously.
Product Details
