Forged Steel Globe Valve

The Mecco compact forged steel globe valve is designed and manufactured in accordance with API 602, ISO 15761, and JB/T 7746 standards. It is available in pressure ratings of CL150, CL300, CL600, CL800, and CL1500 (or PN16–PN250). If CL2500 or other pressure ratings are required, the design can follow ASME B16.34 or GB/T 12224. The operating temperature range is -29°C to 538°C. The standard configuration is reduced bore; full bore can be provided upon contractual agreement.
Size:
NPS 1/2~~NPS 2 (DN15~~DN50), other sizes can be custom manufactured upon request.
Material:
Body materials are selected according to customer orders. Common materials include A105, LF2, F11, F22, F5, F9, F91, F304, F316, F304L, F316L, F304H, F316H, F321, F347, F310, F310H, F44, F51, F53, F55, F60, F20, F904L, N04400, N08825, N06625, N10276, N06600, N08800. Other uncommon materials can be customized as required.
Trim/Stem:
Trim and stem materials are configured according to API 602 standards or customer requirements.
Construction:
Bolted bonnet, pressure-seal bonnet, with straight-through or Y-pattern flow paths.
Operation:
Manual, electric, pneumatic, etc.
