Forged Steel Check Valve

The Mecco compact forged steel check valve is also designed and manufactured according to API 602, ISO 15761, and JB/T 7746 standards, with pressure ratings of CL150, CL300, CL600, CL800, and CL1500 (or PN16–PN250). For CL2500 or other pressure requirements, the valve can be designed per ASME B16.34 or GB/T 12224. Operating temperature is -29°C to 538°C. The standard design is reduced bore; full bore is available by contract specification.
Size:
NPS 1/2~~NPS 2 (DN15~~DN50), other sizes can be custom manufactured upon request.
Material:
Body materials are selected according to customer orders. Common materials include A105, LF2, F11, F22, F5, F9, F91, F304, F316, F304L, F316L, F304H, F316H, F321, F347, F310, F310H, F44, F51, F53, F55, F60, F20, F904L, N04400, N08825, N06625, N10276, N06600, N08800. Other uncommon materials can be customized as required.
Trim/Stem:
Trim and stem materials are configured according to API 602 standards or customer requirements.
Construction:
Bolted bonnet, pressure-seal bonnet, with straight-through and Y-pattern flow paths; available in lift type and swing type based on disc movement.
Operation:
Automatic valve, no manual operation.
