Forged Steel Gate Valve

MECCO Compact Forged Steel Check Valves are designed and manufactured in accordance with API 602, ISO 15761, JB/T 7746, and other relevant standards. Pressure ratings include CL150, CL300, CL600, CL800, and CL1500 (or PN16 to PN250). If the customer requires CL2500 or other pressure classes, the valves can be designed in accordance with ASME B16.34 or GB/T 12224. Operating temperature range: -29℃ to 538℃. The standard configuration is reduced bore; full bore can be provided upon request as specified in the contract.
Size:
NPS1/2~~NPS2 (DN15~~DN50), other sizes can be custom manufactured.
Material:
3.3. Body materials according to customer order requirements, A105, LF2, F11, F22, F5, F9, F91, F304, F316, F316, F304L, F316L, F304H, F316H, F321, F347, F310, F310H, F44, F51, F53, F55, F60, F20, F904L, N04400, N08825, N06625, N10276, N06600, N08800 and other materials are commonly used by our company; other uncommon materials can be custom manufactured as requested.
Internal parts/Stem:
Internal parts and stem materials configured according to API602 standard or customer requirements.
Structure:
Bolted bonnet, self-sealing bonnet, etc.; flow passages include straight-through and Y-type; valve disc motion types include rising stem and rotary lift.
Operation mode:
Automatic valves, no manual operation.
