Cast Steel Globe Valve

The Mecco cast steel globe valves are designed and manufactured in compliance with API 623, BS 1873, and GB/T 12235 standards. They are available in pressure ratings of CL150, CL300, CL600, CL900, CL1500, and CL2500 (or PN16–PN420). If other ratings are needed, ASME B16.34 or GB/T 12224 can be applied. The operating temperature range is -29°C to 538°C.
Size:
NPS 2~~NPS 24 (DN50~~DN600); sizes beyond this range can be custom manufactured upon request.
Material:
Body materials are selected according to customer orders. Common cast materials include WCB, LCB, WC6, WC9, WC5, C12, C12A, CF8, CF8M, CF3, CF3M, CF10, CF10M, CF8C, CK20, CK3MCuN, A4, 5A, 6A, CN7M, CN3MN, M30C, CU5MCuC, CW6MC, CW12MW, CY40. Other uncommon materials can be customized upon request.
Trim/Stem:
Trim and stem materials are configured according to API 623 and GB/T 12235 standards or customer requirements.
Construction:
Bolted bonnet, pressure-seal bonnet, rising stem with yoke; disc structure available as guided non-balanced type or sleeve-type balanced type. Flow path types include straight-through (T-type), Y-pattern, angle type, or Z-type, or other custom designs based on customer requirements.
Operation:
Manual, gear-operated, electric, pneumatic, electro-hydraulic, etc.
