Bellows Seal Valve

For applications with extremely strict sealing requirements—such as toxic, flammable, explosive, or highly corrosive media—bellows seals are employed. Both gate valves and globe valves can be designed with bellows sealing. Their design incorporates a dual sealing structure of bellows combined with packing to ensure zero leakage. The previously mentioned standards for gate and globe valves apply here, along with additional reference to bellows valve standards such as MSS SP-117, GEST 89/140, JB/T14315, and JB/T11150.
Size:
According to specific valve.
Material:
Body material is selected based on customer order; both casting and forging are applicable.
Internal Parts/Stem:
Internal parts and stem materials are configured according to the valve's design standards, and can also be customized per customer requirements.
Structure:
Bellows-sealed bonnet; valve body as per general valve structure.
Operation Mode:
Manual, gear-operated, electric, pneumatic, electro-hydraulic, etc.
